Fail Safe HVSL2-2-LD4-STD-35-UNV-O-EDC1 2" Wide HVSL Linear Steel, 2' Length, Standard Illumination Level, 3500K, 120-277V, Opal Polycarbonate Lens, Single Circuit, Non-Dimming

PRODUCT FAMILY SPECIFICATIONS

Housing

• Heavy duty, 18 ga. steel housing and end caps provide rigid construction
• Stainless-steel and die-formed aluminum available
• End caps provided with 7/8" KO for continuous row mounting
• Pendant mount standard with (2) 7/8" KOs in the housing back (all lengths except 2’). Stem sets ordered seperately as accessory item
• Finished in matte white paint standard. Optional architectural colors available
• Electrostatically applied, matte white powder coat finish; gloss white, silver, black, bronze, dark platinum available; Custom colors available (supply RAL number, paint chips, or paint manufacturer catalog number). 16 architectural colors available.


Fasteners

• White painted Hex-head screws (4) secure the lens to the housing
• Stainless steel TORX®T20 (SF1) with center reject pin and allen head with center pin reject screws (SF3) optional
• Optional flush side screws (FSS or FSSTP) painted matte white


Lens

• One-piece extruded UV stabilized, diffuse polycarbonate
• Unique linear ribbed design provides even light distribution while obscuring LED boards
• Internal ribs and smooth exterior reduce dirt build-up and facilitates cleaning.
• Nominal lens thickness = 0.085"


Reflector

• 18 ga. Steel with white high reflectance polyester powder coat finish. Reflector serves as driver and wireway cover.
• Reflector serves as driver and wireway cover


Mounting

• Surface mount standard, wall or ceiling.
• Continuous row using end knock-outs

Light-Emitting Diode (LED)

• LEDs available in 3000K, 3500K, 4000K and 5000K
  with minimum 80 CRI.


Transformer/Driver

• Electronic driver. 0-10V dimming standard
• Optional 10% and 1% dimming

Compliance

• cULus listed for damp locations standard
• Wet location under covered ceiling optional, wall or ceiling mount


Warranty

• Five-year warranty on LEDs and electrical
• Fail-Safe will repair or replace any vandal resistant / high abuse luminaire, that is deemed non-funcational due to physical damage to the luminaire exterior housing or polycarbonate lens.
  The luminaire must be installed correctly, and the warranty does not include any interior component, nor does it include damage due to gunfire, paint, caustic material / chemicals, disastrous or abnormal events.
