Halo Recessed Commercial PR4M24MD8FSMW 4" LED Module with Self-Flanged Shallow Reflector, Field Selectable 2000/3000/4000 Lumens, Medium/ Wide Beam Reversible Distribution, 80 CRI, Selectable 3000K/3500K/4000K, Matte White Ring, Self-Flanged Reflector

PRODUCT FAMILY SPECIFICATIONS

LED Module

• Integrated self-flanged reflector with multiple finish options
• Patented SeleCCTable color temperature technology and selectable lumen output for selection in the field
• Integrated dip switches for color and lumen selection
• Field Selectable CCT 3000K / 3500K / 4000K
• Discrete (Fixed) CCT options in 2700K and 5000K
• Low and high selectable lumen ranges:
• Low Lumen: 1000lm / 1500lm / 2000lm (nominal)
• High Lumen: 2000lm / 3000lm / 4000lm (nominal)
• Discrete (fixed) lumen models in 1000lm, 1500lm, 3000lm (nominal); use to meet lighting power density codes
• Available in 80 CRI or 90 CRI (nominal) with color accuracy within 3 SDCM
• LED array uses a plurality of mid-power surface mount LEDs delivering high flux and excellent efficiency.
• Passive cooling achieves L70 at 50,000 hours
• Integral connector for quick link to the housing flex


LED Module - Optics

• Reversible "Flip" Lens
• "Flip" lens is reversible offering medium / wide beam options
• Lens ships in medium beam. Twist-to-lock feature allows conversion to wide beam in the field without tools.
• Micro-prismatic lens is precision molded optical polymer
• Louvered Wall Wash
• Optional field installed wall wash kit offers 360° rotation, allowing the housing to be installed in any orientation.

LED Module - Reflector

• Integrated self-flanged reflector with LED array and lens
• Finish options: matte white, matte metallic silver, and dark bronze

LED Module - Retention

• Module/reflector is securely retained in the housing with (2) torsion springs holding the flange tightly to the ceiling
