Juno Iota IIS 125 HE SM 125W Emergency Inverter, High Efficiency, Surface Mount

PRODUCT DESCRIPTION

The IOTA IIS 125 HE SM is a UL Listed stand-alone modified sine wave output inverter designed to provide power to designated emergency lighting fixtures. In a power loss situation, the IOTA IIS 125 HE SM will supply 125W of power from the onboard battery supply. The IOTA IIS 125 HE SM works in conjunction with incandescent, LED, and fluorescent lamp and fixture types and will automatically run switched, normally-on, or normally-off designated emergency fixtures. The IIS 125 HE SM is ideal for applications requiring an emergency source for lighting arrangements that utilize multiple lamp and fixture types. The IIS 125 HE SM is designed for high-efficiency performance and is certified in the CA Title 20 Appliance Efficiency Database. The IIS 125 HE CG includes dimming relay leads to accommodate 0-10V dimming applications. The IIS 125 HE CG features increased inrush capability to prevent shutdown caused by inrush currents, allowing operation of loads at the full rated output of the unit with no need for circuit de-rating. The IIS 125 HE SM features a surface mount design and comes with a three-year warranty and seven-year pro-rata battery warranty.

PRODUCT SPECIFICATIONS

Input Voltage ................................................................................... (Dual) 120/277V, 60Hz
Input Rating (bulk).................................................................................................180 Watts
Output Voltage ................................................................................ (Dual) 120/277V, 60Hz
Output Power ................................................... 125 Watts (@ .9 leading to .9 lagging PF)
Lamps Operated................................................................LED, Fluorescent, Incandescent
Transfer Time..................................................................................................... < 1 second
Emergency Operation ....................................................................................... 90 minutes
Voltage Regulation (emergency).............................................................................. +/- 10%
Frequency Regulation (emergency)........................................................................... +/- 3%
Load Power Factor Range ............................................................. .9 leading to .9 lagging
Operating Temp................................................................................................ 20° to 30° C
Battery...........................................................................Valve Regulated Lead Acid (VRLA)
Weight.....................................................................................................................45.0 lbs.
Certifications ................................................................................................. UL 924 Listed
CA T20 Appliance Efficiency Database
