Kim Lighting 1SA-SARA2-54L-500-35K8-3-CLR-SQ-UNV-BLT-7PR-SF LED Area Light, Single Arm Mount, 54 LEDs, 9000 Lumens, 3500K, 80 CRI, Type III Dist, Clear Glass Lens, Mount Square Pole, 120-277V, Black Matte Textured, 7-Pin Photocell Receptacle, Single Fuse

PRODUCT FAMILY SPECIFICATIONS

CONSTRUCTION

• One piece die-cast housing, low copper (<0.6% Cu) Aluminum Alloy with integral
  cooling ribs over the optical chamber and electrical compartment
• Solid barrier wall separates optical and electrical compartments
• Double-thick wall with gussets on the support-arm mounting end
• Housing forms a half cylinder with 55° front face plane providing a recess to allow a flush single-latch detail
• All hardware is stainless steel or electro-zinc plated steel
• Finish: fade and abrasion resistant, electrostatically applied, thermally cured, triglycidal isocyanurate (TGIC) polyester powdercoat
• One-piece die-cast, low copper (<0 6% Cu) aluminum alloy lens frame with 1" minimum depth around the gasket flange
• Optional clear 1/8" thick tempered glass lens retained by eight steel clips with full silicone gasketing around the perimete
• Optional, fixture supplied with a one-piece flat, clear, UV stabilized polycarbonate, fully gasketed, replacing the standard tempered glass lens. CAUTION: Use only when
  vandalism is anticipated to be high. Useful life is limited by UV discoloration from sunlight.
  A program of regular inspection and periodic replacement is highly recommended to
  maintain optimum fixture performance
• One-piece extruded aluminum arm with internal bolt guides and fully radiussed top and bottom
• Luminaire-to-pole attachment is by internal draw bolts, and includes a pole reinforcing plate with wire strain relief
• Arm is circular cut for specified round pole
• Optional cast, low copper aluminum horizontal slip-fitter with adaptor plate to
  secure the luminaire to 2" IPS pipe size arms
• Optional cast aluminum wall mount plate assembly. Attaches to the wall over the
  junction box. Luminaire attaches to the wall plate

OPTICS

• Optical cartridge system consisting of a die cast heat sink, LED Total Internal Reflection (TIR) optics, gasket and bezel plate
• Molded silicone gasket ensures a weatherproof seal around each individual LED
• Features revolutionary individual LED optical control based on high performance TIR
  optical designs
• Optional BackLight Control for complete control of unwanted backlight
• IP65 Optical assembly
• Type 1, 2, 3, 4, 4W, 5W, 5QM, R, and L standard distributions
• Available in Monochromatic Amber, 2700K, 3000K, 3500K, 4000K and 5000K
• Die-cast, low copper aluminum heat sink modules provide thermal transfer at PCB level
• Anodized aluminum heat sink modules

INSTALLATION

• Fixtures must be grounded in accordance with national, state and/or local electrical
  codes. Failure to do so may result in serious personal injury

ELECTRICAL

• Dimming range from 10% to 100% through the use of standard 0-10V interface on the programmable driver
• Modular wiring harness in the service area provides user access to the dimming circuitry
• Optional factory programmed dimming profile
• Surge protection: 10kV surge suppression
• SF for 120, 277, 347 Line volts DF for 208, 240, 480 Line volts

CONTROLS

• 7-pin Receptacle and Button Photocell

CERTIFICATIONS AND LISTINGS

• Listed to UL1598 and CSA C22.2#250.0- 24 for wet location and 40˚C ambient
  temperatures
• IDA approved, 3000K and warmer CCTs only
• RoHS compliant
• This product qualifies as a "designated country construction material" per FAR
  52.225-11 Buy American-Construction Materials under Trade Agreements effective
  6/06/2020. See Buy American Solutions


WARRANTY

• 5 year warranty
