Metalux 4WSNLED-LD4-40SL-F-UNV-EL14W-L840-CD1-U 4' Premium LED Wraparound, 4000 Lumens, Fros Acrylic Lens, 120-277V, 14W Emergency Battery Pack, 80 CRI, 4000K, 0-10V Dimming

PRODUCT FAMILY SPECIFICATIONS

Construction

• Housing consists of die formed cold rolled steel.
• Ends formed with the housing for strength and provisions for continuous row aligners

• Steel end plates with 7/8" KO and light-seal embossment
• Driver cover can be removed without tools


Controls

• WSNLED is Powered by Fifth Light, with standard a 0-10V continuous dimming driver that works with any 0-10V control/ dimmer

• Combine with energy saving products like occupancy sensors, daylighting controls and lighting relay panels to maximize energy savings

• Dimming range is 10% to 100%; varies by control device
• Other driver options include step-dim or, go fully digital with the Digital Addressable Lighting Interface (DALI) drivers


Electrical

• Long-Life LED system coupled with electrical driver to deliver optimal performance
• LED’s available in 3000K, 3500K, 4000K and 5000K with a min. 80 CRI
• Projected life at 70% lumen maintenance is nearly 150,000 hours with TM21 rating up to L87 > 60,000 hours
• Electronic drivers are available for 120-277V applications. A 0-10V dimming driver is standard


Emergency Battery Pack Options

• Optional 120V-277V integral emergency battery pack is available in 10-watts to meet critical lifesafety lighting requirements
• The 90-minute batteries provide constant power to the LED system, ensuring code compliance

• The patented EZ Key prevents accidental discharge of the battery during construction


Finish

• Multistage iron phosphate pretreatment ensures maximum bonding and rust inhibitor
• High reflective paint after fabrication, baked white enamel finish is standard


Channel/Wireway Cover

• Die formed heavy gauge steel
• Tight fit for ease of maintenance

Shielding

• Acrylic end caps with a frost finish to improve aesthetics and illumination
• Clear acrylic lens coupled with LED optical materials providing superior brightness control while improving overall light distribution and aesthetics
• This distribution is further enhanced through the use of embedded prisms within the lens on both side and bottom


Installation

• Fixture may be surface, pendant, or stem mounted
• See accessories below for ordering information


Compliance

• Indoor luminaires are cULus listed for 25ºC ambient environments, damp location listed, RoHS compliant, and LED modules comply with IESNA LM-79 and LM-80 standards
• DesignLights Consortium Qualified and classified for both DLC Standard and DLC Premium, refer to www.designlights.org for details.
• Suitable for use in clothes closets when installed in accordance with the NEC 410.16 spacing requirements
• Can be used for State of California Title 24 high efficacy luminaire


Product Warranty

• 5-year limited warranty
