RAB BOA3R 30/21/18/15/8W Field-Adjustable Linear LED Light, 3000/3500/4000K, 1110-4094 Lumens, 93-94 CRI
RAB BOA3R 30/21/18/15/8W Field-Adjustable Linear LED Light, 3000/3500/4000K, 1110-4094 Lumens, 93-94 CRI
Regular price
Price:
$266.96
Regular price
Price:
Sale price
$266.96
Unit price
per
Ordering a Large Quantity?
Request a quote
description
| Field Adjustability | |
|
Field Adjustable
|
Field Adjustable Light Output:
|
| 30W/21W/18W/15W/8W (factory default 30W) | |
| Color Temperature Selectable: | |
| 3000K, 3500K and 4000K (factory default 4000K) | |
|
Compliance
|
|
|
UL Listed
|
Suitable for damp locations
|
|
IESNA LM-79 & LM-80 Testing
|
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
|
|
DLC Listed
|
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
|
|
Electrical
|
|
|
Driver
|
Constant Current, Class 2, 120-277V, 50/60 Hz:
|
| 30W: 120V: 0.25A, 208V: 0.15A, 240V: 0.13A, 277V: 0.12A | |
| 21W: 120V: 0.18A, 208V: 0.11A, 240V: 0.10A, 277V: 0.09A | |
| 18W: 120V: 0.15A, 208V: 0.09A, 240V: 0.09A, 277V: 0.08A | |
| 15W: 120V: 0.13A, 208V: 0.08A, 240V: 0.07A, 277V: 0.07A | |
| 7.5W: 120V: 0.07A, 208V: 0.05A, 240V: 0.05A, 277V: 0.05A | |
|
Dimming Driver
|
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
|
|
THD
|
2.39% at 120V, 6.47% at 277V
|
|
Power Factor
|
99.7% at 120V, 93.9% at 277V
|
|
Surge Protection
|
2 kV
|
|
Continuous Runs
|
Maximum wattage for a continuous run should not exceed 600W
|
|
LED Characteristics
|
|
|
LEDs
|
Long-life, high-efficacy, surface-mount LEDs
|
|
Color Uniformity
|
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
|
|
Performance
|
|
|
Lifespan
|
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
|
|
Performance Data
|
|
|
Construction
|
|
|
Cold Weather Starting
|
The minimum starting temperature is -4°F (-20°C)
|
|
Maximum Ambient Temperature
|
Suitable for use in up to 104°F (40°C)
|
|
Housing
|
Aluminum
|
|
Lens
|
Polycarbonate frosted flat lens
|
|
Reflector
|
Polyethylene Terephthalate (PET)
|
|
Finish
|
Formulated for high durability and long-lasting color
|
|
Green Technology
|
Mercury and UV free. RoHS-compliant components.
|
|
Installation
|
|
|
Mounting
|
Trimless design for a clean and seamless appearance
|
|
Other
|
|
|
5-Year Limited Warranty
|
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
|
|
Note
|
Not compatible with T-Grid Ceilings
|
