Home > RAB Lighting > RAB Lighting SA-TB/RGB Bollard, Tunable White 2200-4000K Color Temperature, 29-3/4" Mounting Height, Bronze Finish
RAB Lighting SA-TB/RGB Bollard, Tunable White 2200-4000K Color Temperature, 29-3/4" Mounting Height, Bronze Finish
RAB Lighting SA-TB/RGB Bollard, Tunable White 2200-4000K Color Temperature, 29-3/4" Mounting Height, Bronze Finish
Regular price
Price:
$298.20
Regular price
Price:
Sale price
$298.20
Unit price
per
Ordering a Large Quantity?
Request a quote
description
| Compliance | |
|
UL Listed
|
Suitable for wet locations
|
|
IP Rating
|
Ingress protection rating of IP65 for dust and water
|
|
IESNA LM-79 & LM-80 Testing
|
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
|
|
LED Characteristics
|
|
|
LEDs
|
Long-life, high-efficacy, discrete, surface-mount LEDs
|
|
Color Tuning
|
Yes, 2200K-4000K and 16+ million colors to choose from using the Lightcloud Blue mobile app.
|
| Default Setting at 3000K. | |
|
Color Consistency
|
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
|
|
Color Uniformity
|
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for (SSL) Products, ANSI C78.377-2017.
|
|
Electrical
|
|
|
Driver
|
Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.07A, 208V: 0.04A, 240V: 0.04A, 277V: 0.04A
|
|
THD
|
11.2% at 120V, 14.0% at 277V
|
|
Power Factor
|
97.3% at 120V, 70.8% at 277V
|
|
Dim to Off
|
No
|
|
Aux Power Supply
|
No
|
|
Construction
|
|
|
Cold Weather Starting
|
The minimum starting temperature is -40°F (-40°C)
|
|
Maximum Ambient Temperature
|
Suitable for use in up to 113°F (45°C)
|
|
Housing
|
Die-cast aluminum
|
|
Lens
|
Polycarbonate lens
|
|
Gaskets
|
High-temperature silicone
|
|
Finish
|
Formulated for high durability and long-lasting color
|
|
Green Technology
|
Mercury and UV free. RoHS-compliant components.
|
|
Installation
|
|
|
Mounting
|
4pcs anchor bolts for mounting
|
|
Lightcloud
|
|
|
Light Shows
|
No, this product is not compatible with dynamic color changing Light Shows. Contact RAB for more information.
|
|
Other
|
|
|
5-Year Limited Warranty
|
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
|
