Home > RAB Lighting > RAB SLIMSY LED Wallpack with Adjustable Throw, Adjustable Light Output 38/28/18W, 3000K Color Temperature, 120-277V, Photocell
RAB SLIMSY LED Wallpack with Adjustable Throw, Adjustable Light Output 38/28/18W, 3000K Color Temperature, 120-277V, Photocell
RAB SLIMSY LED Wallpack with Adjustable Throw, Adjustable Light Output 38/28/18W, 3000K Color Temperature, 120-277V, Photocell
Regular price
Price:
$192.00
Regular price
Price:
Sale price
$192.00
Unit price
per
Ordering a Large Quantity?
Request a quote
description
| LED Characteristics | |
|
LEDs
|
Long-life, high-efficiency, surface-mount LEDs
|
|
Electrical
|
|
|
Driver
|
38W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.31A, 208V: 0.19A, 240V: 0.16A, 277V: 0.14A
|
| 28W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.23A, 208V: 0.15A, 240V: 0.13A, 277V: 0.11A | |
| 18W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.15A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A | |
|
Dimming Driver
|
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
|
|
Photocell
|
120-277V selectable photocell that can be turned on and off.
|
|
Aux Power Supply
|
Yes
|
|
Dim to Off
|
Yes
|
|
Construction
|
|
|
Cold Weather Starting
|
The minimum starting temperature is -40°F (-40°C)
|
|
Maximum Ambient Temperature
|
Suitable for use in up to 104°F (40°C)
|
|
Housing
|
Die-cast aluminum
|
|
Lens
|
Tempered glass
|
|
Gaskets
|
High-temperature silicone
|
|
Finish
|
Formulated for high durability and long-lasting color
|
|
Green Technology
|
Mercury and UV free. RoHS-compliant components.
|
|
Compliance
|
|
|
UL Listed
|
Suitable for wet locations
|
|
IESNA LM-79 & LM-80 Testing
|
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
|
|
ADA Compliant
|
Meets ADA Requirements for wall-mounted luminaires.
|
|
IP Rating
|
Ingress protection rating of IP65 for dust and water
|
|
Dark Sky Approved
|
Conforms to the requirements listed by the International Dark-Sky Association for "Dark Sky" approval. The Fixture Seal of Approval provides objective, third-party certification for luminaries that minimize glare, reduce light trespass, and don't pollute the night sky.
|
|
Trade Agreements Act Compliant
|
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
|
|
DLC Listed
|
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
|
|
LUNA
|
This product has received the Design Lights Consortium's LUNA listing. Designed to meet LUNA 5.1 requirements.
|
| LUNA Product Code: S-862JF2 | |
|
Installation
|
|
|
Mounting
|
Heavy-duty mounting bracket with spring-hinged housing and "kick stand" allow for easy installations. Conduit entries on back and both sides.
|
|
Other
|
|
|
5-Year, No-Compromise Warranty
|
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
|
Download PDF Specification Share your knowledge of this product. Be the first to write a review »
