RAB Lighting SWISHFA2X2/D10 29W Field Adjustable 2' x 2' LED SWISH Recessed Center Basket Troffer, 3500K/4000K/5000K, 2432-4913 Lumens, 83 CRI, 120-277V, Dimmable, White Finish
RAB Lighting SWISHFA2X2/D10 29W Field Adjustable 2' x 2' LED SWISH Recessed Center Basket Troffer, 3500K/4000K/5000K, 2432-4913 Lumens, 83 CRI, 120-277V, Dimmable, White Finish
Regular price
Price:
$106.90
Regular price
Price:
Sale price
$106.90
Unit price
per
Ordering a Large Quantity?
Request a quote
description
| Field Adjustability | |
|
Field Adjustable
|
Field Adjustable Light Output:
|
| 2' x 2': 39W/29W/19W (factory default 29W) | |
| Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K) | |
|
Compliance
|
|
|
UL Listed
|
Suitable for damp locations
|
|
IESNA LM-79 & LM-80 Testing
|
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
|
|
IC Rated
|
Suitable for direct contact with insulation
|
|
Trade Agreements Act Compliant
|
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
|
|
DLC Listed
|
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
|
|
Electrical
|
|
|
Driver
|
Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 0.25A, 208V: 0.14A, 240V: 0.12A, 277V: 0.11A
|
|
Dimming Driver
|
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
|
|
THD
|
4.65% at 120V, 16.05% at 277V
|
|
Power Factor
|
99.8% at 120V, 97.4% at 277V
|
|
Surge Protection
|
2 kV
|
|
Construction
|
|
|
Cold Weather Starting
|
The minimum starting temperature is -22°F (-30°C)
|
|
Ambient Temperature
|
Suitable for use in up to 104°F (40°C)
|
|
Housing
|
Die-formed, 20-gauge, cold-rolled steel
|
|
Reflector
|
Integral reflector (on the sides) with high reflectance finish, optimized for uniform distribution.
|
|
Lens
|
Frosted polycarbonate lens
|
|
Finish
|
Formulated for high durability and long-lasting color
|
|
Green Technology
|
Mercury and UV free. RoHS-compliant components.
|
|
Installation
|
|
|
Mounting
|
Recessed ceiling
|
|
LED Characteristics
|
|
|
LEDs
|
Long-life, high-efficacy, surface-mount LEDs
|
|
Color Stability
|
LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period
|
|
Color Uniformity
|
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
|
|
Performance
|
|
|
Lifespan
|
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
|
|
Other
|
|
|
5-Year, No-Compromise Warranty
|
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
|
|
Compatible Accessories
|
RMKEZPAN[2X2][1X4][2X4]
|
| Recessed mounting kit | |
| SMKEZPAN[2X2][1X4][2X4] | |
| Surface mounting kit | |
| EMB-[9][15][25] | |
| 0-10V Dimmable 120-347V emergency driver |
